适用箱型
Suitable For Containers |
ISO标准20′、40′、APL45′
ISO standard 20′、40′、APL45′ |
额定起重量
Rated Hoisting Weight |
41吨+10%偏心载荷
41 tonnes±10%eccentric loading |
吊具四角吊耳负重
Lifting Lugs In End Beam |
10吨×4
4×10tonnes |
自重
Weight |
8.9吨
8.9 tonnes |
伸缩
Telescopic Motion |
∼25秒（20′到40′）
From 20′to40′in 25 seconds |
导板
Guide Arm Speed |
3∼5秒(180°)
180° in 3∼5 seconds |
转销
Twistlock Rotation |
1秒（90°）
90° approximately in 1 seconds |
电源
Power Supply And Consumption |
交流380V，频率50Hz,功率7.5kW
380VAC 50Hz 7.5kW |
表面处理
Surface Comditioning |
冲砂 SA2½ ，2层环氧富锌底漆，2层丙烯酸面漆
Sand-blasted SA2½ ,two coats of zinc-rich epoxy primer and two ccats of acrylic top coat |
防护等级
Protection Class IP55 |
IP55 |
液压
Hydraulics |
系统压力10MPa
System pressure 10MPa |
环境温度
Suitable Ambient Temperature |
-20℃∼+40℃ |
